Description
With the performance boost from a WD Green SATA SSD, you can browse the web, play a game, or simply start your system in a flash. Lightweight and shock resistant, WD Green SSDs use no moving parts and help keep your data safe from loss in the case of accidental bumps and drops.
Highlights of the WD 120GB Green SATA 6Gb/s 2.5" SSD M.2 2280
- Improved performance for everyday computing
- Solid state reliability
- Less power, more play
Specifications
Summary
- Product Description
- WD Green PC SSD WDS120G2G0B - solid state drive - 120 GB - SATA 6Gb/s
- Type
- Solid state drive - internal
- Capacity
- 120 GB
- NAND Flash Memory Type
- Triple-level cell (TLC)
- Form Factor
- M.2 2280
- Interface
- SATA 6Gb/s
- Data Transfer Rate
- 600 MBps
- Features
- DEVSLP SATA low power mode, S.M.A.R.T.
- Dimensions (WxDxH)
- 22 mm x 80 mm x 1.5 mm
- Weight
- 6.51 g
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- Solid state drive - internal
- Capacity
- 120 GB
- NAND Flash Memory Type
- Triple-level cell (TLC)
- Form Factor
- M.2 2280
- Interface
- SATA 6Gb/s
- Features
- DEVSLP SATA low power mode, S.M.A.R.T.
- Width
- 22 mm
- Depth
- 80 mm
- Height
- 1.5 mm
- Weight
- 6.51 g
Performance
- Drive Transfer Rate
- 600 MBps (external)
- Internal Data Rate
- 545 MBps
Reliability
- MTBF
- 1,000,000 hours
Expansion & Connectivity
- Interfaces
- 1 x SATA 6 Gb/s - M.2 Card
- Compatible Bay
- M.2 2280
Power
- Power Consumption
- 80 mW (active) , 2800 mW (read) , 2800 mW (write) , 30 mW (sleep) , 10 mW (DevSleep)
Software & System Requirements
- Software Included
- WD SSD Dashboard
Miscellaneous
- Compliant Standards
- UL, TUV, VCCI, BSMI, FCC, KC
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 70 °C
- Min Storage Temperature
- -55 °C
- Max Storage Temperature
- 85 °C
- Shock Tolerance (operating)
- 1500 g @ 0.5 ms half-sine
- Vibration Tolerance (operating)
- 5 g @ 10-2000 Hz
- Vibration Tolerance (non-operating)
- 4.9 g @ 7-800 Hz
