Description
Marketing description is not available.
Highlights of the TP LINK RE220 AC750 Wi-Fi Range Extender
- Boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
- Miniature size and wall-mounted design make it easy to deploy and move flexibly
- Ethernet port allows the extender to function as a wireless adapter to connect wired devices
-
An access point and wireless adapter
The Ethernet port of RE220 can easily turn your wired Internet connection into a wireless access point. It can also function as a wireless adapter to connect wired devices. -
High-speed mode for maximized performance
High-speed mode uses one dedicated Wi-Fi band as backhaul and another dedicated Wi-Fi band as an access point to maximize the bandwidth on extender's Wi-Fi. -
Universal compatibility
The RE220 is compatible with any of your existing Wi-Fi router or access points, making it easy to expand and strengthen your Wi-Fi network.
Specifications
Summary
- Product Description
- TP-Link RE220 - Wi-Fi range extender
- Device Type
- Wi-Fi range extender
- Form Factor
- External
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz, 5 GHz
- Performance
- Maximum data rate (2.4 GHz): 300 Mbps , Maximum data rate (5 GHz): 433 Mbps
- OS Required
- UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows NT, Microsoft Windows 98 Second Edition / Windows 2000, Microsoft Windows XP / Vista / 7 / 8 / 10
- Dimensions (WxDxH)
- 7.52 cm x 6.58 cm x 11 cm
Detailed Specification
General
- Device Type
- Wi-Fi range extender
- Width
- 7.52 cm
- Depth
- 6.58 cm
- Height
- 11 cm
Networking
- Form Factor
- External
- Connectivity Technology
- Wireless
- Data Transfer Rate
- 750 Mbps
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz, 5 GHz
- Performance
- Maximum data rate (2.4 GHz): 300 Mbps , Maximum data rate (5 GHz): 433 Mbps
- Wi-Fi Rating
- AC750
- Status Indicators
- Power, 5 GHz, 2.4 GHz, Wi-Fi
- Features
- Wi-Fi Multimedia (WMM) support, Wi-Fi Protected Setup (WPS), reset button
- Encryption Algorithm
- 128-bit WEP, 64-bit WEP, 152-bit WEP, WPA-PSK, WPA2-PSK
- Compliant Standards
- IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Aerial
- Antenna
- Internal
- Antenna Qty
- 3
Expansion / Connectivity
- Interfaces
- 1 x 100Base-TX - RJ-45
Miscellaneous
- Compliant Standards
- FCC, RoHS
Power
- Power Device
- Internal power supply
- Power Consumption Operational
- 6.5 Watt
Software / System Requirements
- OS Required
- UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows NT, Microsoft Windows 98 Second Edition / Windows 2000, Microsoft Windows XP / Vista / 7 / 8 / 10
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
