Specifications
Summary
- Product Description
- TP-Link Archer A7 - wireless router - 802.11a/b/g/n/ac - desktop
- Device Type
- Wireless router - 4-port switch (integrated)
- Enclosure Type
- Desktop
- WAN Ports Qty
- 1
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz / 5 GHz
- Data Transfer Rate
- 1.75 Gbps
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP
- Routing Protocol
- Static IP routing
- Features
- Firewall protection, Stateful Packet Inspection (SPI), DoS attack prevention, dynamic DNS server, print server, MAC address filtering, IPv6 support, parental control, IP address filtering, Wi-Fi Multimedia (WMM) support, virtual server support, Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, reset button, bandwidth control, IPv4 support, port triggering, IP-MAC binding, DHCP client, WDS bridge
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac
- Dimensions (WxDxH)
- 24.3 cm x 16.06 cm x 3.25 cm
- System Requirements
- UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7, Windows 8 / 8.1 / 10
Detailed Specification
General
- Device Type
- Wireless router - 4-port switch (integrated)
- Enclosure Type
- Desktop
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
- Frequency Band
- 2.4 GHz / 5 GHz
- Data Transfer Rate
- 1.75 Gbps
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP
- Routing Protocol
- Static IP routing
- Encryption Algorithm
- 128-bit WEP, 64-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK
- Wi-Fi Rating
- AC1750
- Features
- Firewall protection, Stateful Packet Inspection (SPI), DoS attack prevention, dynamic DNS server, print server, MAC address filtering, IPv6 support, parental control, IP address filtering, Wi-Fi Multimedia (WMM) support, virtual server support, Wi-Fi Protected Setup (WPS), DHCP server, Samba support, FTP server, reset button, bandwidth control, IPv4 support, port triggering, IP-MAC binding, DHCP client, WDS bridge
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, FCC, RoHS
- Status Indicators
- Port status, power, link/activity
Expansion / Connectivity
- Interfaces
- LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 , USB 2.0: 1 x 4 pin USB Type A
Aerial
- Aerial
- External detachable
- Antenna Qty
- 3
- Directivity
- Omni-directional
Power
- Power Device
- External power adapter
Miscellaneous
- Cables Included
- 1 x network cable
Software / System Requirements
- OS Required
- UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7, Windows 8 / 8.1 / 10
Dimensions & Weight
- Width
- 24.3 cm
- Depth
- 16.06 cm
- Height
- 3.25 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
