Description
Add an SPDIF digital audio output and standard 3.5mm audio/microphone connections to your system through USB. The ICUSBAUDIO2D External USB Sound Card lets you add an S/PDIF digital audio output and standard 3.5mm analog audio/microphone connections to your system through USB - a convenient way to bypass or replace an internal sound card without having to open the computer case.
For home-theater quality sound, the USB DAC (digital-to-analog converter) offers 96KHz / 24-bit sampling rates for both playback and recording, and a 3.5mm S/PDIF port with support for Dolby Digital 5.1 surround sound (AC3) and DTS pass-through (5.1 surround sound is supported in Windows only).
This versatile USB audio adapter features an integrated 3.5mm 4-position TRRS connection for your headphones or combination headset/microphone. Also a convenient external volume control for quick adjustments, a hardware EQ switch for Bass or Treble boosting, and an LED status bar to display the current sampling rate.
Highlights of the StarTech.com USB Stereo Audio Adapter External Sound Card with SPDIF Digital Audio
- Add home-theater surround sound support with the integrated digital S/PDIF output
- Replace an internal sound card easily with a compact external USB device
- Adjust sound output easily with external volume and EQ controls
Specifications
Summary
- Product Description
- StarTech.com USB Sound Card w/ SPDIF Digital Audio & Stereo Mic - External Sound Card for Laptop or PC - SPDIF Output (ICUSBAUDIO2D) - sound card
- Device Type
- Sound card
- Enclosure Type
- External
- Interface Type
- USB 2.0
- Dimensions (WxDxH)
- 4.6 cm x 4.7 cm x 1.6 cm
- Weight
- 36 g
- Colour
- Black
- Sound Output Mode
- Stereo
- DAC Resolution
- 24-bit
- Sample Rate
- 96 kHz (max)
- System Requirements
- Linux, Apple MacOS X 10.x or later, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits)
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: MU15MMS, MU6MMS
Detailed Specification
General
- Device Type
- Sound card
- Form Factor
- External
- Interface Type
- USB 2.0
- Width
- 4.6 cm
- Depth
- 4.7 cm
- Height
- 1.6 cm
- Weight
- 36 g
- Enclosure Colour
- Black
Audio Output
- Sound Output Mode
- Stereo
- DAC Resolution
- 24-bit
- Sample Rate
- 96 kHz (max)
Expansion / Connectivity
- Interfaces
- 1 x headphones - mini-phone stereo 3.5 mm , 1 x microphone - mini-phone stereo 3.5 mm , 1 x SPDIF output - mini TOSLINK
Miscellaneous
- Compliant Standards
- FCC, RoHS
Software / System Requirements
- Software
- Drivers & Utilities
- OS Required
- Linux, Apple MacOS X 10.x or later, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits)
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years , Technical support - lifetime
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 60 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
Compatibility Information
- Designed For
- P/N: MU15MMS, MU6MMS
