StarTech.com USB-C USB-A Dock - Hybrid Triple Monitor Docking Station DP/HDMI 4K 60Hz 85W PD
Description
Marketing description is not available.
Highlights of the StarTech.com USB-C USB-A Dock - Hybrid Triple Monitor Docking Station DP/HDMI 4K 60Hz 85W PD
- FLEXIBLE MULTI DISPLAY SETUP: USB 3.1 Gen 2 10Gbps Type-C/A dock supports dual or triple monitor setup (up to 3x 4K 60Hz), using any combination of the 3x DisplayPort 1.4 & 3x HDMI 2.0 w/ HDR ports
- 85W POWER DELIVERY: Power & charge USB-C/Thunderbolt 3 workstation laptops/ultrabooks incl Lenovo X1 Carbon, ThinkPad P Series, Dell Latitudes, Precision, XPS 15, HP Spectre, ZBook & MacBook Pro 16
- UNIVERSAL DOCKING STATION: Hybrid dock includes combo 2-in-1 USB-C/USB-A USB-IF Certified host cable; DisplayLink dock supports up to 3 extended displays on Macbook Pro/Air with Intel processor or Apple M1 chip; compatible w/ Windows, macOS and Chrome OS
- 6-PORT USB HUB: 4x USB-A (1x 10Gbps), 2x USB-C (1x 10Gbps), incl. 2x BC 1.2 fast charge always-on front ports; USB-C Gen 1 & USB-A laptops will only support downstream port speeds up to USB 5Gbps
- DEPLOYMENT READY: Docking station features a K-slot, 1m combo host cable, mounting holes, & MAC address changer for IT management; Gigabit Ethernet & headset ports; Windows, MacOS, Chrome OS
Specifications
Summary
- Product Description
- StarTech.com USB-C & USB-A Dock, Hybrid Universal Triple Monitor Laptop Docking Station w/ DisplayPort & HDMI 4K 60Hz, 85W Power Delivery, 6x USB Hub, Ethernet, Audio, USB 3.1 Gen 2 10Gbps - Multi-Monitor Dock (DK31C3HDPDUE) - docking station - USB-C - 3 x HDMI, 3 x DP - GigE
- Product Type
- Docking station
- Docking Interface
- USB-C
- Video Interfaces
- 3 x HDMI, 3 x DP
- Dimensions (WxDxH)
- 8.4 cm x 23.3 cm x 3.7 cm
- Weight
- 365 g
- Colour
- Grey, black
- Networking
- Gigabit Ethernet
- Power
- Power adapter 85 Watt AC 100/240 V
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Product Type
- Docking station
- Width
- 8.4 cm
- Depth
- 23.3 cm
- Height
- 3.7 cm
- Weight
- 365 g
- Enclosure Colour
- Grey, black
Video
- Max Resolution Details
- 4096 x 2160 - 60 Hz
Networking
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
- Interfaces
- 3 x USB 3.1 Gen 2 - 9 pin USB Type A , 1 x USB-C 3.1 Gen 2 - 24 pin USB-C , 1 x USB-C 3.1 Gen 1 (data only) - 10 pin USB-C , 3 x display / video - 19 pin HDMI Type A , 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 , 3 x display / video - 20 pin DisplayPort , 1 x headphone/microphone combo jack - mini-phone 3.5 mm , 1 x USB-C 3.0 - 24 pin USB-C , 1 x SuperSpeed USB 3.0 - 9 pin USB Type A
Miscellaneous
- Cables Included
- 1 x USB-C/USB-A screw-lock cable - external - 1 m
- Features
- Security lock slot (cable lock sold separately), USB pass-through connector, UASP transfer protocol, Preboot Execution Environment (PXE) support, full duplex support, up to 3 monitors support, HDR support
- Security Slot Type
- Kensington security slot
- Compliant Standards
- FCC, RoHS, USB Battery Charging Specification Rev. 1.2, DisplayPort 1.2, DisplayPort 1.4, UASP (USB Attached SCSI Protocol), USB Power Delivery 3.0
Power
- Power Device
- Power adapter
- Voltage Required
- AC 100/240 V
- Power Provided
- 85 Watt
System Requirements
- OS Required
- Apple MacOS X 10.6, Windows 10
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Dimensions & Weight (Shipping)
- Shipping Width
- 9 cm
- Shipping Depth
- 25 cm
- Shipping Height
- 17.1 cm
- Shipping Weight
- 1.7 kg
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
