Description
Convert and extend a Gigabit Ethernet connection up to 24.8 miles/40 km over Single Mode SC fiber. The ET91000SM402 1000 Mbps Gigabit Single Mode Fiber Media Converter SC (40 km) lets you extend a Gigabit Ethernet network over single mode fiber by up to 40km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Highlights of the StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km - 1000 Mbps
- Link loss forwarding, remote status monitoring help ensure maximum up-time
- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
- Rugged steel casing for added durability in harsh environments
Specifications
Summary
- Product Description
- StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km - 1000 Mbps (ET91000SM402) - fibre media converter - GigE
- Device Type
- Fibre media converter - RJ-45 / SC single-mode
- Form Factor
- External
- Localisation
- North America, United Kingdom, Europe
- Cabling Type
- 1000Base-LX, 1000Base-SX, 1000Base-T
- Data Transfer Rate
- 1 Gbps
- Optical Wave Length
- 1310 nm
- Data Link Protocol
- GigE
- Max Transfer Distance
- 40 km
- Power
- AC 120/230 V
- Dimensions (WxDxH)
- 9.5 cm x 16 cm x 2 cm
- Weight
- 0.6 kg
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA
Detailed Specification
General
- Device Type
- Fibre media converter
- Form Factor
- External
- Colour
- Black
- Localisation
- North America, United Kingdom, Europe
Networking
- Connectivity Technology
- Wired
- Cabling Type
- 1000Base-LX, 1000Base-SX, 1000Base-T
- Data Link Protocol
- GigE
- Data Transfer Rate
- 1 Gbps
- Optical Wave Length
- 1310 nm
- Max Transfer Distance
- 40 km
- Features
- Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, rugged
Expansion / Connectivity
- Interfaces
- 1 x Ethernet 1000Base-T - RJ-45 female , 1 x Ethernet 1000Base-LX/1000Base-SX - SC single-mode female x 2
Miscellaneous
- MTBF
- 65,000 hours
- Compliant Standards
- Plug and Play, FCC, RoHS
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V
Dimensions & Weight
- Width
- 9.5 cm
- Depth
- 16 cm
- Height
- 2 cm
- Weight
- 0.6 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 60 °C
- Humidity Range Operating
- 10 - 90%
Compatibility Information
- Designed For
- P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA
