Description
The DP2DVIS DisplayPort to DVI Active Single Link adapter lets you connect your DisplayPort video source (desktop PC, laptop, etc.) to a DVI-D monitor, projector or display, including televisions and Apple Cinema Display HD, eliminating the expense of having to upgrade to a DisplayPort-capable monitor. Unlike passive adapters, this DP to DVI converter offers an active conversion for use with any DisplayPort output - ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity). Supporting resolutions up to 1920x1200, this compact device provides a simple solution for converting DisplayPort output for compatibility with existing DVI monitors, televisions or projectors.
Highlights of the StarTech.com DisplayPort to DVI Active Adapter
- DISPLAYPORT TO DVI ADAPTER: DisplayPort 1.2 (HBR2) to DVI-D single-link adapter connects a DVI display/projector supporting 1920x1200 & 1080p 60Hz | EDID/DDC pass-through ensures compatibility between source & display | 5.7" (15cm) attached cable
- COMPATIBILITY: Active video converter supports DP or DP++ source incl workstations, desktops (AMD/Nvidia), laptops, small form factor computers & docking stations | AMD Eyefinity Certified ideal for use with Radeon Pro Series Workstation Graphics
- CONNECT A PRIMARY OR SECONDARY DISPLAY: Connect a DVI monitor or projector or add a second display to your workstation | Compact design |Tested w/ DVI cables up to 25ft | Supports Apple Cinema Display HD
- LATCHING DISPLAYPORT & SCREW LOCKING DVI: Latching DP connector ensures a solid host connection | Supports DVI screw locking cable to prevent cable from coming loose or accidental disconnection
- EASY TO USE: With no software or drivers required, the DP to DVI adapter converter works with any OS including Windows, Ubuntu and macOS; DisplayPort male to DVI female adapter dongle
Specifications
Summary
- Product Description
- StarTech.com DisplayPort to DVI Adapter - Active Conversion - 1920x1200 - DP to DVI Single Link Converter for DVI-D Display (DP2DVIS) - DisplayPort adapter - 20 cm
- Type
- DisplayPort adapter
- Features
- HDCP compliant
- Length
- 20 cm
- Connector
- DisplayPort - male
- Connector (Second End)
- DVI-D - female
- Compliant Standards
- FCC, RoHS
- Colour
- Black
- Manufacturer Warranty
- 3-year warranty
- Designed For
- P/N: DK30C2DAGPD, DKM30CHDPD, DKWG30DPHPD, DKWG30DPHPDU, MST30C2DPPD, SP123DP, SV231QDPU34K, TB32DP14, TB32DP2T, TB3CDK2DP, TB3CDK2DPUE, TB3CDOCKDP, TB3DK2DHV, TB3DK2DHVUE, TB3DK2DPPD, TB3DK2DPPDUE, TB3DK2DPW, TB3DK2DPWUE, TB3DKDPMAW, TB3DKDPMAWUE, TB3DKM2DP, TB3DKM2DPL
Detailed Specification
General
- Type
- DisplayPort adapter
- Features
- HDCP compliant
- Length
- 20 cm
- Colour
- Black
Connectivity
- Connector
- 20 pin DisplayPort - male
- Connector (Second End)
- 24+1 pin digital DVI - female
Miscellaneous
- Compliant Standards
- DisplayPort 1.1a, FCC, RoHS
Manufacturer Warranty
- Service & Support
- 3-year warranty
Compatibility Information
- Designed For
- P/N: DK30C2DAGPD, DKM30CHDPD, DKWG30DPHPD, DKWG30DPHPDU, MST30C2DPPD, SP123DP, SV231QDPU34K, TB32DP14, TB32DP2T, TB3CDK2DP, TB3CDK2DPUE, TB3CDOCKDP, TB3DK2DHV, TB3DK2DHVUE, TB3DK2DPPD, TB3DK2DPPDUE, TB3DK2DPW, TB3DK2DPWUE, TB3DKDPMAW, TB3DKDPMAWUE, TB3DKM2DP, TB3DKM2DPL
