Description
This rack-mount KVM console provides complete keyboard, monitor and mouse control for eight computers. The rack-mount console installs into 1U of rack space, offering a space-efficient solution for complete console control.
Highlights of the StarTech.com 8 Port KVM Console for Server Rack - 19in
- TECH SPECIFICATIONS: Rackmount KVM Console, 19" Active Matrix TFT LCD Monitor, 1280 x 1024, 8 port VGA KVM switch w/ 6 ft. cables, 99 key full keyboard + numeric keypad & trackpad; Supports USB 2.0
- PROFESSIONAL & SECURE: Customizable hot-keys, on-screen display (OSD), multi-level user security, user access levels / port permissions, & auto scan
- INTEGRATED DESIGN: Combines a KVM + Console w/ integrated power supply into 1U of rack space allowing space for other equipment. Mount depth: 23.8" [60.5 cm] to 35" [89 cm] (incl. mounting hardware)
- HEAVY DUTY: LCD KVM drawer has durable steel construction and heavy duty rail design that supports frequent use in operating environments from 0C to 40C (32F to 104F) with an MTBF of 50,000 hours
- TESTED & PROVEN: This OS independent rack console is universally compatible w/ leading servers and backed by a StarTech.com 2-year warranty and free lifetime 24/5 multilingual technical support
-
Maximize your IT budget, minimize your hassle
This 8-port KVM switch provides all the essential controls you'll need to manage your server room at a low cost. The console features a built-in touchpad, keyboard for intuitive control and an LCD display. -
Maximize your screen space
This versatile LCD console has a 19" screen. The increased screen space allows you to run multiple applications on the same screen, increasing your productivity. -
Clutter-free monitoring
The console slides out from 1U of rack space, enabling you to easily monitor and control eight servers and even more if connecting through a KVM switch. The rackmount VGA console features a handle for easy sliding in and out of the server rack, keeping your area organized and clutter free. -
Hassle-free system integration
The rackmount LCD features an 8-port KVM module, which enables you to connect it directly to eight servers. You can also connect to additional servers by connecting to KVM switches in a cascaded (daisy-chained) configuration.
Specifications
Summary
- Product Description
- StarTech.com 8 Port Rackmount KVM Console with 6ft Cables, Integrated KVM Switch with 19" LCD Monitor, Fully Featured 1U LCD KVM Drawer- OSD KVM, Durable 50,000 MTBF, USB + VGA Support - 19in. LCD KVM Console (RKCONS1908K) - KVM console - 19"
- Device Type
- KVM console - 19"
- KVM Switch
- PS/2, USB - 8 ports
- Keyboard Layout
- US
- Daisy Chaining
- Yes
- Features
- Keyboard, touchpad, 8 port KVM switch
- Aspect Ratio
- 5:4
- Native Resolution
- 1280 x 1024
- Pixel Pitch
- 0.264 mm
- Brightness
- 250 cd/m²
- Contrast Ratio
- 1000:1
- Colour Support
- 16.7 million colours
- Input Connectors
- VGA
- Colour
- Black
- Dimensions (WxDxH)
- 48.3 cm x 64.3 cm x 4.3 cm
- Height (Rack Units)
- 1U
- Weight
- 13.5 kg
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
- Compliant Standards
- UL, FCC, RoHS, WEEE, PSE Mark, RCM
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Display Type
- KVM console / TFT active matrix
- Diagonal Size
- 19"
- Daisy Chaining
- Yes
- Built-in Devices
- 8 port KVM switch
- Aspect Ratio
- 5:4
- Native Resolution
- 1280 x 1024
- Pixel Pitch
- 0.264 mm
- Brightness
- 250 cd/m²
- Contrast Ratio
- 1000:1
- Colour Support
- 16.7 million colours
- Colour
- Black
- Dimensions (WxDxH)
- 48.3 cm x 64.3 cm x 4.3 cm
- Height (Rack Units)
- 1U
- Weight
- 13.5 kg
Input
- Type
- Keyboard, touchpad
KVM
- Type
- KVM switch - 8 ports
- Keyboard / Mouse Interface
- PS/2, USB
- Max Resolution
- 1280 x 1024
Connectivity
- Interfaces
- 2 x VGA , 2 x USB 2.0 , 8 x KVM , 2 x PS/2
Miscellaneous
- Included Accessories
- 8 x M5 cage nuts, 8 x M5 screws, 4 x mounting rails
- Cables Included
- 8 x keyboard / mouse / video cable
- Rack Mounting Kit
- Included
- MTBF
- 50,000 hour(s)
- Compliant Standards
- UL, FCC, RoHS, WEEE, PSE Mark, RCM
- Localisation
- Australia, Japan, New Zealand, North America, United Kingdom, Europe
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
