Description
Extend two USB 2.0 connections with power, by up to 330ft over Cat5 or Cat6 cable. The USB2002EXT2 2-Port USB Extender lets you extend USB 2.0 devices over Cat 5 or better Ethernet cable at distances of up to 330ft (100m). A local transmitter power adapter provides up to 500 mA of power per port with no power adapter required at the remote end, letting you access and power almost any USB 2.0 device in locations where a power outlet may be unavailable.
This USB extender provides support for data transfer rates of up to 480 Mbps, is Plug-and-Play and hot-swap compatible, and is also backwards compatible with USB 1.x devices.
This versatile USB extender offers a fast, easy, and flexible solution for business or industrial applications with durable metal housing, and an included surface-mounting bracket kit.
Highlights of the StarTech.com 2 Port USB 2.0 Extender over Cat5 or Cat6 - Up to 330 ft (100m)
- Two USB 2.0 ports on remote unit over a single Cat5/Cat6 cable
- Maximum extension distance of up to 100m (330ft) over Cat5 cabling
- Rugged, metal enclosure with surface-mounting bracket kit included
- High Speed USB 2.0 compliant with support for data transfer rates up to 480 Mbps
- 500mA of power per port
- No external power required at remote end as power is delivered over Cat5/Cat6
- 4kV Contact and 8kV Air Electrical Static Discharge (ESD) protection
- No driver or software required
- Plug-and-Play and hot-swap compatible
Specifications
Summary
- Product Description
- StarTech.com Replaced by USB2002EXT2NA - 2 Port USB 2.0 over Cat5 or Cat6 Extender Kit - Local / Remote Power - 330 ft - USB Extender (USB2002EXT2) - USB extender - USB, USB 2.0
- Device Type
- USB extender
- Ports Qty
- 2
- Form Factor
- External
- Data Transfer Rate
- 480 Mbps
- Data Link Protocol
- USB, USB 2.0
- Transmission Medium
- CAT 5/6
- Max Transfer Distance
- 100 m
- Power
- AC 120/230 V
- System Requirements
- Linux, Apple MacOS X, Microsoft Windows XP 64-bit Edition, Microsoft Windows 2000 / XP, Microsoft Windows Server 2003, Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows 7 64-bit Edition, Microsoft Windows Server 2003 x64 Edition, Microsoft Windows Vista (32/64 bits), Microsoft Windows CE 6.0
- Dimensions (WxDxH)
- 7.6 cm x 10 cm x 2.6 cm
- Weight
- 0.6 kg
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: 35FCREADBK3
Detailed Specification
General
- Device Type
- USB extender
- Form Factor
- External
- Colour
- Black
Networking
- Ports Qty
- 2
- Connectivity Technology
- Wired
- Data Link Protocol
- USB, USB 2.0
- Data Transfer Rate
- 480 Mbps
- Max Transfer Distance
- 100 m
- Status Indicators
- Power, link OK, link/activity
Expansion / Connectivity
- Interfaces
- 1 x USB 2.0 - Type A male , 2 x USB 2.0 - Type A female
Miscellaneous
- Compliant Standards
- FCC, RoHS
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V
Software / System Requirements
- OS Required
- Linux, Apple MacOS X, Microsoft Windows XP 64-bit Edition, Microsoft Windows 2000 / XP, Microsoft Windows Server 2003, Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows 7 64-bit Edition, Microsoft Windows Server 2003 x64 Edition, Microsoft Windows Vista (32/64 bits), Microsoft Windows CE 6.0
Dimensions & Weight
- Width
- 7.6 cm
- Depth
- 10 cm
- Height
- 2.6 cm
- Weight
- 0.6 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 10 - 90%
Compatibility Information
- Designed For
- P/N: 35FCREADBK3
