Description
This active optical DisplayPort 1.4 cable lets you connect your DP laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. The built-in active signal booster ensures a reliable connection at a distance up to 15 m (49.2 ft.) between your DisplayPort enabled devices.
This 8K DisplayPort cable supports all DP 1.4 features: Resolutions up to 8K at 60Hz; HDCP 2.2 support; High Bit Rate 3 (HBR3) bandwidth of 32.4Gbps; High Dynamic Range (HDR); Multi-Stream Transport (MST) for daisy-chaining multiple monitors; 32 uncompressed digital audio channels; Backward compatible with 5K 60Hz, 4K 120Hz and previous generations of DP.
This durable yet lightweight active DP 1.4 cable features both copper and optical fiber conductors enabling a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed. The DisplayPort connectors also feature latches that provide a secure connection between your devices.
Comprised of a fiber and copper wire mix, this active cable is less susceptible to EMI interference, for a clear and reliable audio/video signal.
Note: This cable features unidirectional architecture, please refer to the "display" label on the HDMI connectors to ensure installed in the correct direction.
Highlights of the StarTech.com 15m / 49.2ft Active Optical DisplayPort 1.4 Cable - 8K 60Hz
- DISPLAYPORT 1.4 OPTICAL CABLE: 49.2'/15m hybrid copper & fiber DisplayPort 1.4 cable; 8K 60Hz (7680x4320), 4K 120Hz (3840x2160), 32.4Gbps, HDR10, HBR3, 32ch audio (5.1/7.1/Dolby TrueHD/Atmos), MST, GTC for precise audio channel timing; future-proof for 8K
- ACTIVE CIRCUITRY: DisplayPort Active Optical cable with unique DisplayPort bus powered Electro-Optical amplifier boosts video signals over longer distances up to 15 meters (49.2 feet) (no external power supply needed); Latching DP connectors
- RELIABLE DESIGN: DP Active Optical Cable (AOC) w/ flexible PVC jacket and strain relief absorb stress of frequent bends; Internal wire manager, metal connector sub-structure & Al-Mylar Foil with Braid provide EMI shielding & superior signal integrity
- APPLICATIONS: Ideal for home, office, boardroom, classroom; works w/ professional workstations: Dell XPS 11th Gen, HP Z2 G8 Tower with Radeon Vega Frontier/Pro WX Series/W5500/Pro Duo & NVIDIA Quadro P graphics cards; Use with Ultra HD (UHD) monitors/TV
- SPECS: 15 m (49.2 ft) | Black | DisplayPort version 1.4 cable | DP Male/Male Cord | PVC Jacket | Al-Mylar foil w/ Braid | DSC 1.2, HDCP 2.2 | Works w/ DP 1.3/1.2 (1080p/4K) | 2-Year Warranty | Note: DP connector labelled "Display End" connects to display
Specifications
Summary
- Product Description
- StarTech.com 15m /49.2ft Active Optical DisplayPort 1.4 Cable - 8K 60Hz - DisplayPort cable - DisplayPort to DisplayPort - 15 m
- Type
- DisplayPort cable
- Features
- 8K support, Active Optical Cable (AOC), EMI protection, HDR support, DisplayPort Multi-Stream Transport (MST), High Bit Rate 3 (HBR3)
- Length
- 15 m
- Connector
- 20 pin DisplayPort - male - latched
- Connector (Second End)
- 20 pin DisplayPort - male - latched
- Compliant Standards
- DisplayPort 1.4
- Colour
- Black
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Type
- DisplayPort cable
- Shielding Material
- Aluminum mylar foil with braid
- Jacket Material
- PVC
- American Wire Gauge (AWG)
- 28
- Plated Connector
- Nickel
- Features
- 8K support, Active Optical Cable (AOC), EMI protection, HDR support, DisplayPort Multi-Stream Transport (MST), High Bit Rate 3 (HBR3)
- Length
- 15 m
- Colour
- Black
- Weight
- 422 g
Connectivity
- Connector
- 20 pin DisplayPort - male - latched
- Connector (Second End)
- 20 pin DisplayPort - male - latched
Miscellaneous
- Compliant Standards
- DisplayPort 1.4, RoHS, REACH, HDCP 2.2
Dimensions & Weight (Shipping)
- Shipping Width
- 26.5 cm
- Shipping Depth
- 26.5 cm
- Shipping Height
- 7.8 cm
- Shipping Weight
- 700 g
- Service & Support
- Limited lifetime warranty
