Description
Store your servers, network and telecommunications equipment in an adjustable 12U open-frame rack. The 4POSTRACK12U 12U Server Rack lets you store your servers, network and telecommunications equipment in a sturdy, adjustable depth open-frame rack.
Designed with ease of use in mind, this 12U rack offers easy-to-read markings for both rack units (U) and depth, with a wide range of mounting depth adjustments (22 - 40in) that make it easy to adapt the rack to fit your equipment.
This durable 4-post rack supports a static loading capacity of up to 1200lbs (544kg), and offers compliance with several industry rack standards (EIA/ECA-310, IEC 60297, DIN 41494) for a universal design that's compatible with most rack equipment.
For a complete server storage solution that saves you time and hassle, the rack includes optional accessories such as casters, leveling feet and cable management hooks. The base is also pre-drilled for securely fastening the rack to the floor if needed, providing you with additional stability to better suit your server environment.
Highlights of the StarTech.com 12U Adjustable Depth Open Frame 4 Post Server Rack w/ Casters / Levelers & Cable Hooks
- ADJUSTABLE DEPTH: 12U Open frame rack with four vertical rails rack for servers & network equipment w/ adjustable mounting depth 22" to 40" (56cm to 101cm); maximize available space with 25" (64 cm) height, for integration in utility or server close
- EASY ASSEMBLY: Mobile computer equipment rack with assembly instructions & easy-to-follow online video; compact flat pack shipping/packaging design to avoid damage and facilitate problem-free installations
- COLD ROLLED STEEL: Durable 4 Post 19" EIA/ECA-310-E open frame designed for ventilation with 12U mounting height, 1220lb (544kg)) capacity, 3 install options included: casters, levelling feet, or base-plate to secure rack to the floor
- HARDWARE INCLUDED: Rolling rack with cage nuts & screws to mount equipment, easy to read Units (U) & depth adjustment markings, cable management hooks for organization, with required assembly tools
- STARTECH.COM ADVANTAGE: Trusted by IT professionals for a variety of applications, this rack supports server depth equipment and can be used for servers, UPSs, patch panels, switches, and other networking or AV equipment. StarTech.com 2 Year Warranty and Free Lifetime Technical Support
Specifications
Summary
- Product Description
- StarTech.com 12U 19" Open Frame Server Rack, 4 Post Adjustable Depth 23-41" Mobile, Free Standing Rolling Network/Computer Equipment Data Rack, Dell PowerEdge, HP ProLiant ThinkServer - Adjustable Server Rack (4POSTRACK12U) - rack - 12U
- Product Type
- Rack
- Rack Type
- Open frame
- Package Content
- Phillips screwdriver, 16 M6 nuts, 16 M6 screws, 2 base brackets, 2 top brackets, 48 M8 bolts, 8 corner sections, 48 M8 washers, M8 (13mm) wrench, 4 casters, 4 x levelling feet, 16 M6 flange nuts, M6 (10mm) wrench, 4 x centre sections, 2 right vertical rails, 2 left vertical rails, 4 grounding wires, 16 M6 flat washers, 24 M6 cage nuts, 24 PVC cup washers, 24 M6 Philips head screws, 4 cable management hooks, 4 hook mounting screws
- Colour
- Black
- Height (Rack Units)
- 12U
- Product Material
- Steel
- Dimensions (WxDxH)
- 60 cm x 66.18 cm x 63.75 cm
- Weight
- 17 kg
- Features
- Adjustable depth, flat pack, 4 post rack mountable, 4 post
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: CABCAGENT62B, CABCAGENTS62, CABCAGENUT2B, CABCAGENUT6B, CABCAGENUTS2, CABCAGENUTSB, CABSCREWM52B, CABSCREWM5B, CABSCREWM62B, CABSCREWM6B, CABSCREWSB, CABSCREWSM5, CABSCREWSM5B, CABSCREWSM62, CABSCREWSM6B, CABSCRWS1224, CABSCRWSM62B
Detailed Specification
General
- Product Type
- Rack
- Rack Type
- Open frame
- Product Material
- Steel
- Package Content
- Phillips screwdriver, 16 M6 nuts, 16 M6 screws, 2 base brackets, 2 top brackets, 48 M8 bolts, 8 corner sections, 48 M8 washers, M8 (13mm) wrench, 4 casters, 4 x levelling feet, 16 M6 flange nuts, M6 (10mm) wrench, 4 x centre sections, 2 right vertical rails, 2 left vertical rails, 4 grounding wires, 16 M6 flat washers, 24 M6 cage nuts, 24 PVC cup washers, 24 M6 Philips head screws, 4 cable management hooks, 4 hook mounting screws
- Height (Rack Units)
- 12U
- Width
- 60 cm
- Depth
- 66.18 cm
- Height
- 63.75 cm
- Weight
- 17 kg
- Inner Dimensions
- 46.5 cm x 55.9 cm x 53.8 cm
- Colour
- Black
Miscellaneous
- Weight Limit
- 544.3 kg
- Mounting Kit
- Included
- Features
- Adjustable depth, flat pack, 4 post rack mountable, 4 post
- Compliant Standards
- EIA-310-E, RoHS, DIN 41494, IEC 60297-3-100, ECA-310-E
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years , Technical support - lifetime
Compatibility Information
- Designed For
- P/N: CABCAGENT62B, CABCAGENTS62, CABCAGENUT2B, CABCAGENUT6B, CABCAGENUTS2, CABCAGENUTSB, CABSCREWM52B, CABSCREWM5B, CABSCREWM62B, CABSCREWM6B, CABSCREWSB, CABSCREWSM5, CABSCREWSM5B, CABSCREWSM62, CABSCREWSM6B, CABSCRWS1224, CABSCRWSM62B
