Description
Smart. Safe. Secure. Seagate provides drives specifically for surveillance storage for years. SkyHawk is built to keep systems in the field longer and reduce the need for post-deployment support.
Highlights of the Seagate 1TB SkyHawk 3.5" SATA 6Gb/s 64MB Surveillance Hard Drive
- ImagePerfect firmware supports 24/7 surveillance-optimized workloads tuned to record ~90% of the time and play back video footage the remaining 10%, and supports more cameras recording at higher resolutions than traditional drives
- Great workload allows SkyHawk to perform reliably in write-intensive surveillance systems - 3x the workload rating of a desktop-class drive
- Rotational vibration (RV) sensors allow drives to maintain performance in RAID and multi-drive systems, giving customers the flexibility to grow with the booming
- NVR market and scale their systems when more storage is needed
- ATA streaming support sustains recordings from up to 64 HD cameras for smooth, uninterrupted footage
- Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions
- Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
Specifications
Summary
- Product Description
- Seagate SkyHawk Surveillance HDD ST1000VX005 - hard drive - 1 TB - SATA 6Gb/s
- Type
- Hard drive - internal
- Capacity
- 1 TB
- Form Factor
- 3.5"
- Interface
- SATA 6Gb/s
- Data Transfer Rate
- 600 MBps
- Buffer Size
- 64 MB
- Spindle Speed
- 5900 rpm
- Features
- 24x7 availability, ImagePerfect firmware
- Dimensions (WxDxH)
- 101.85 mm x 146.99 mm x 20.2 mm
- Weight
- 415 g
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- Hard drive - internal
- Capacity
- 1 TB
- Form Factor
- 3.5"
- Interface
- SATA 6Gb/s
- Buffer Size
- 64 MB
- Features
- 24x7 availability, ImagePerfect firmware
- Width
- 101.85 mm
- Depth
- 146.99 mm
- Height
- 20.2 mm
- Weight
- 415 g
Performance
- Drive Transfer Rate
- 600 MBps (external)
- Internal Data Rate
- 180 MBps
- Spindle Speed
- 5900 rpm
Reliability
- MTBF
- 1,000,000 hours
- 24x7 Operation
- Yes
- Non-Recoverable Errors
- 1 per 10^14
Expansion & Connectivity
- Interfaces
- 1 x SATA 6 Gb/s - 7 pin Serial ATA
- Compatible Bay
- 3.5"
Power
- Power Consumption
- 1.8 Watt (start) , 5.6 Watt (active) , 4 Watt (idle) , 0.5 Watt (sleep) , 0.5 Watt (standby)
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 70 °C
