Description
Extended battery module for the Eaton 9PX. The Eaton 9PX UPS provides energy efficient power protection for small & medium Datacenters, IT rooms and Infrastructure. Delivering double conversion protection with 40% less energy usage and 28% more power 9PX is the perfect UPS for IT and Facility managers that are concerned by energy cost and are looking for next generation power protection solutions.
Highlights of the Eaton 9PX EBM 240V 8kVA & 11kVA
- Warranty: 2 years
-
Graphical LCD display
It provides clear information on the UPS's status and measurements on a single screen which tilts 450 for ease-of-viewing. -
Availability and flexibility
The internal bypass allows service continuity in case of internal fault, a maintenance bypass is also available for easy replacement of the UPS without powering down critical systems. -
Paralleling functionality
Paralleling functionality to achieve twice the power of unitary products using Hot Sync technology! -
Load segment control
It enables prioritized shut downs of nonessential equipment to maximize battery runtime for critical devices.
Specifications
Summary
- Product Description
- Eaton 9PX 9PXEBM240 - battery enclosure - Lead Acid
- Device Type
- Battery enclosure - rack-mountable / external
- Rack Size
- 19" - 3U
- Weight
- 65 kg
- Output Voltage
- 240 V
- Battery
- Lead Acid
- Battery Form Factor
- Internal
- Dimensions (WxDxH)
- 44 cm x 68 cm x 13 cm
- Designed For
- 9PX 9PX11KIBP, 9PX11KIBP31, 9PX11KIRTNBP, 9PX11KIRTNBP31, 9PX6KIBP31, 9PX6KIRTNBP31, 9PX8KIBP, 9PX8KIBP31, 9PX8KIRTNBP, 9PX8KIRTNBP31
Detailed Specification
General
- Device Type
- Battery enclosure - rack-mountable / external
- Battery Enclosure Type
- Internal
- Height (Rack Units)
- 3U
- Rack Size
- 19"
Power Device
- Output Voltage
- 240 V
Battery
- Technology
- Lead Acid
Miscellaneous
- Cables Included
- Power cable 40 cm
- Rack Mounting Kit
- Optional
Dimensions & Weight
- Width
- 44 cm
- Depth
- 68 cm
- Height
- 13 cm
- Weight
- 65 kg
Compatibility Information
- Designed For
- Eaton 9PX 9PX11KIBP, 9PX11KIBP31, 9PX11KIRTNBP, 9PX11KIRTNBP31, 9PX6KIBP31, 9PX6KIRTNBP31, 9PX8KIBP, 9PX8KIBP31, 9PX8KIRTNBP, 9PX8KIRTNBP31
