Description
The Eaton 9PX UPS provides energy efficient power protection for small & medium Datacenters, IT rooms and Infrastructure. Delivering double conversion protection with 40% less energy usage and 28% more power 9PX is the perfect UPS for IT and Facility managers that are concerned by energy cost and are looking for next generation power protection solutions.
Highlights of the Eaton 9PX 11000i RT6U HotSwap Netpack (11000VA/10000W)
- Double conversion topology
- Constantly monitors power conditions and regulates voltage and frequency
- Provides more real power (watts) to protect more equipment with a 0.9 power factor
- Energy Star qualified, provides the highest efficiency level to reduce energy and cooling costs
- Internal bypass allows service continuity in case of UPS fault
- Next-generation graphical LCD display
- Network card and rackmounting kit delivered as standard
- Compatible with Virtual environments (VMware, Hyper-V, Citrix Xen, Redhat)
- Meter energy consumption (at the UPS level)
- Parallel operation using HotSync technology
- Hot swappable batteries
- Warranty: 2 years
-
Graphical LCD display
It provides clear information on the UPS's status and measurements on a single screen which tilts 450 for ease-of-viewing. -
Availability and flexibility
The internal bypass allows service continuity in case of internal fault, a maintenance bypass is also available for easy replacement of the UPS without powering down critical systems. -
Paralleling functionality
Paralleling functionality to achieve twice the power of unitary products using Hot Sync technology! -
Load segment control
It enables prioritized shut downs of nonessential equipment to maximize battery runtime for critical devices.
Specifications
Summary
- Product Description
- Eaton 9PX 9PX11KIRTNBP - UPS - 10000 Watt - 11000 VA
- Device Type
- UPS - Power Factor Correction (PFC) - rack-mountable / external
- Rack Size
- 19" - 6U
- Weight
- 86 kg
- Input Voltage
- AC 200/208/220/230/240/250 V
- Output Voltage
- AC 200/208/220/230/240/250 V ± 1%
- Power Capacity
- 10000 Watt / 11000 VA
- Input Connectors
- Hardwire
- Output connectors
- 4 x power IEC 60320 C19 , 1 x hardwire
- Battery
- Expandable
- Battery Form Factor
- Plug-in module
- Run Time (Up To)
- 3 min at full load
- Networking
- Ethernet 10/100, RS-232, USB
- Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, HTTP, TFTP, SSH, CLI
- System Requirements
- Linux, Apple MacOS X, Microsoft Windows Vista / XP / 7, Microsoft Windows Server 2008
- Dimensions (WxDxH)
- 44 cm x 70 cm x 26 cm
- Environmental Standards
- ENERGY STAR
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- UPS - Power Factor Correction (PFC) - rack-mountable / external
- Battery Enclosure Type
- Plug-in module
- Height (Rack Units)
- 6U
- Rack Size
- 19"
Power Device
- UPS Technology
- On-line
- Supported Power Modules Qty
- 12
- Input Voltage
- AC 200/208/220/230/240/250 V
- Input Voltage Range
- AC 176 - 276 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 40 - 70 Hz
- Input Connectors
- Hardwire
- Power Output Connectors Details
- 4 x power IEC 60320 C19 , 1 x hardwire
- Output Voltage
- AC 200/208/220/230/240/250 V ± 1% - 50/60 Hz
- Power Capacity
- 10000 Watt / 11000 VA
- Surge Suppression
- Yes
Battery
- Type
- Expandable
- Run Time (Up To)
- 13 min at half load , 9 min at 70% load
Networking
- Remote Management Interface
- Ethernet 10/100, RS-232, USB
- Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, HTTP, TFTP, SSH, CLI
Expansion / Connectivity
- Interfaces
- 1 x RS-232 - 9 pin D-Sub (DB-9) , 1 x USB - 4 pin USB Type B , 1 x EPO (emergency power off) , 1 x management (Ethernet) - RJ-45
- Expansion Slots
- 1 (total) / 0 (free) x Expansion Slot
Miscellaneous
- Rack Mounting Kit
- Included
- Features
- Advance Battery Management (ABM), LCD display, built-in maintenance bypass, LED indicators, deep discharge protection, automatic self-test
- Compliant Standards
- FCC Class A certified, UL, TUV, UL 1778, CB, IEC 62040-3, IEC 62040-1-1, IEC 62040-2, CSA 22.2, EN 62040-1-1, EN 62040-2
Software / System Requirements
- Software Included
- Intelligent Power Software Suite
- OS Required
- Linux, Apple MacOS X, Microsoft Windows Vista / XP / 7, Microsoft Windows Server 2008
Environmental Standards
- ENERGY STAR
- Yes
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Sound Emission
- 50 dBA
Dimensions & Weight
- Width
- 44 cm
- Depth
- 70 cm
- Height
- 26 cm
- Weight
- 86 kg
