Description
LCD graphics display has text and mimic diagrams that display modes of operation, system parameters and alarms. Connect the device to a network using a 10 or 100 BASE-T connection. Green mode bypasses unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection. Battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance. Automatic internal bypass supplies utility power to the connected loads in the event of a UPS power overload or fault. Scalable runtime allows additional run time to be quickly added as needed. Intelligent battery management maximizes battery performance, life, and reliability through intelligent, precision charging.
Highlights of the APC Smart-UPS SRT UPS 5000 Watt Lead Acid
- Green mode
- Battery failure notification
- LCD graphics display
- ECO Mode
- 10/100 BaseT Connection
-
Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection -
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance -
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms -
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection -
10/100 BaseT Connection
Connect the device to a network using a 10 or 100 BaseT connection
Specifications
Summary
- Product Description
- APC Smart-UPS SRT 5000VA RM - UPS - 4500 Watt - 5000 VA
- Device Type
- UPS - rack-mountable
- Rack Size
- 3U
- Weight
- 54.55 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V ± 3%
- Power Capacity
- 4500 Watt / 5000 VA
- Input Connectors
- Hardwire 3-wire (1PH + N + G)
- Output connectors
- 6 x power IEC 60320 C13 , 4 x power IEC 60320 C19 , 2 x IEC connector
- Battery
- Lead Acid
- Run Time (Up To)
- 4 min at full load
- Networking
- USB
- Colour
- Black
- Dimensions (WxDxH)
- 43.2 cm x 71.9 cm x 13 cm
- Manufacturer Warranty
- 3-year warranty
- Designed For
- P/N: ACDC2513, AR2407, AR2480, AR2487, AR2487G, AR2507, AR2580, AR2587, AR3100G, AR3100TAA, AR3100W, AR3105SP, AR3105W, AR3107G, AR3107SP, AR3300G, AR3300SP, AR3300W, AR3305SP, AR3305W, AR3307SP, AR3307W, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, NBWL0356A
Detailed Specification
General
- Device Type
- UPS - rack-mountable
- Height (Rack Units)
- 3U
- Colour
- Black
Power Device
- UPS Technology
- On-line
- Input Voltage
- AC 230 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 45 - 65 Hz
- Input Connectors
- Hardwire 3-wire (1PH + N + G)
- Power Output Connectors Details
- 6 x power IEC 60320 C13 , 4 x power IEC 60320 C19 , 2 x IEC connector
- Output Voltage
- AC 230 V ± 3% - 50/60 Hz
- Power Capacity
- 4500 Watt / 5000 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 480 Joules
- Efficiency
- 98%
Battery
- Technology
- Lead Acid
- Run Time (Up To)
- 4 min at full load , 11.8 min at half load
- Recharge Time
- 3 hours
- Features
- Maintenance free, sealed, leak-proof
Networking
- Remote Management Interface
- USB
Expansion / Connectivity
- Interfaces
- 1 x serial - RJ-45 , 1 x management (USB) - 4 pin USB Type B , 1 x EPO (emergency power off)
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Features
- Audible alarm, LCD display
- Compliant Standards
- C-Tick, VDE, IEC 60950, EN 50091-2, RoHS, EN 50091-1, REACH, EN 62040-2, IP20, EAC
Software / System Requirements
- Software Included
- APC PowerChute Business Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years , Limited warranty - batteries - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95% (non-condensing)
- Sound Emission
- 55 dBA
Dimensions & Weight
- Width
- 43.2 cm
- Depth
- 71.9 cm
- Height
- 13 cm
- Weight
- 54.55 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 61 cm
- Shipping Depth
- 96 cm
- Shipping Height
- 33 cm
- Shipping Weight
- 63.6 kg
Compatibility Information
- Designed For
- P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC2513, ACF001, ACF002, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR2407, AR2480, AR2487, AR2487G, AR2507, AR2580, AR2587, AR3000, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR8135BLK, NBWL0356A
