Description
High density, double-conversion on-line power protection with scalable runtime. A battery failure notification provides early-warning fault analysis on batteries enabling timely preventive maintenance. ECO Mode by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection. Text and mimic diagrams display modes of operation, system parameters, and alarms.
Highlights of the APC Smart UPS SRT 1000VA
- Low operating and maintenance costs with proven reliability and intelligent battery management
- Avoids costly power problems by keeping your IT equipment and data protected and available
- Peace of mind that comes with full equipment compatibility and reliability of a leader
- Save time with easy and convenient remote accessibility
-
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance -
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection -
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms. -
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Specifications
Summary
- Product Description
- APC Smart-UPS SRT 1000VA - UPS - 1000 Watt - 1000 VA
- Device Type
- UPS - Power Factor Correction (PFC) - rack-mountable / external
- Weight
- 20.5 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 220/230/240 V ± 2%
- Power Capacity
- 1000 Watt / 1000 VA
- Input Connectors
- 1 x power IEC 60320 C14, power BS 1363A, Europlug (power CEE 7/16)
- Output connectors
- 6 x power IEC 60320 C13
- Battery
- Lead Acid
- Run Time (Up To)
- 8.5 min at full load
- Networking
- RS-232, USB
- Colour
- Black
- Dimensions (WxDxH)
- 43.2 cm x 50.5 cm x 8.5 cm
- Environmental Standards
- ENERGY STAR
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- UPS - Power Factor Correction (PFC) - rack-mountable / external
- Colour
- Black
Power Device
- UPS Technology
- On-line
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 50 - 150 / 80 - 150 V
- Frequency Provided
- 50/60 Hz ± 3Hz
- Frequency Required
- 40 - 70 Hz
- Input Connectors
- 1 x power IEC 60320 C14, power BS 1363A, Europlug (power CEE 7/16)
- Power Output Connectors Details
- 6 x power IEC 60320 C13
- Output Voltage
- AC 220/230/240 V ± 2% - 50/60 Hz
- Power Capacity
- 1000 Watt / 1000 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 432 Joules
- Circuit Protection
- Circuit breaker
Battery
- Technology
- Lead Acid
- Run Time (Up To)
- 8.5 min at full load , 21.1 min at half load , 9.8 min at 900 Watts , 13.8 min at 700 Watts , 59.6 min at 200 Watts
- Recharge Time
- 3 hours
- Features
- Maintenance free, sealed, leak-proof
Networking
- Remote Management Interface
- RS-232, USB
Expansion / Connectivity
- Interfaces
- 1 x management (RS-232) - RJ-45 , 1 x EPO (emergency power off) , 1 x management (USB)
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Cables Included
- Power cable 1.83 m , USB cable - external
- Features
- Audible alarm, LCD display, internal bypass, LED indicators, cold-start function, firmware upgradable, automatic self-test, hot-swappable batteries, Eco-Mode, reset breaker
- Compliant Standards
- RoHS, REACH, IP20, EAC
Software / System Requirements
- Software Included
- APC PowerChute Business Edition
Environmental Standards
- ENERGY STAR
- Yes
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years , Limited warranty - batteries - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95% (non-condensing)
- Sound Emission
- 50 dBA
Dimensions & Weight
- Width
- 43.2 cm
- Depth
- 50.5 cm
- Height
- 8.5 cm
- Weight
- 20.5 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 59.4 cm
- Shipping Depth
- 74.9 cm
- Shipping Height
- 24.6 cm
- Shipping Weight
- 29.6 kg
