Name: APC SMART-UPS SRT 1000VA RM 230V
Price: 920.4 GBP
Availability: InStock
Rating: 0.0 (0 reviews)

Description

High density, double-conversion on-line power protection with scalable runtime.

Highlights of the APC SMART-UPS SRT 1000VA RM 230V

Battery failure notification
ECO Mode
Rack/tower convertible

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Specifications

Summary

Product Description: APC Smart-UPS SRT 1000VA RM - UPS - 1000 Watt - 1000 VA

Device Type: UPS - Power Factor Correction (PFC) - rack-mountable

Rack Size: 2U

Weight: 21 kg

Input Voltage: AC 230 V

Output Voltage: AC 220/230/240 V ± 2%

Power Capacity: 1000 Watt / 1000 VA

Input Connectors: 1 x power IEC 60320 C14, power BS 1363A, Europlug (power CEE 7/16)

Output connectors: 6 x power IEC 60320 C13

Battery: Lead Acid

Run Time (Up To): 8.5 min at full load

Networking: RS-232, USB

Colour: Black

Dimensions (WxDxH): 43.2 cm x 50.5 cm x 8.5 cm

Environmental Standards: ENERGY STAR

Manufacturer Warranty: 3-year warranty

Detailed Specification

General

Device Type: UPS - Power Factor Correction (PFC) - rack-mountable

Height (Rack Units): 2U

Colour: Black

Power Device

UPS Technology: On-line

Input Voltage: AC 230 V

Input Voltage Range: AC 50 - 150 / 80 - 150 V

Frequency Provided: 50/60 Hz ± 3Hz

Frequency Required: 40 - 70 Hz

Input Connectors: 1 x power IEC 60320 C14, power BS 1363A, Europlug (power CEE 7/16)

Power Output Connectors Details: 6 x power IEC 60320 C13

Output Voltage: AC 220/230/240 V ± 2% - 50/60 Hz

Power Capacity: 1000 Watt / 1000 VA

Output Waveform: Sinewave

Surge Suppression: Yes

Surge Energy Rating: 432 Joules

Circuit Protection: Circuit breaker

Battery

Technology: Lead Acid

Run Time (Up To): 8.5 min at full load , 21.1 min at half load , 9.8 min at 900 Watts , 13.8 min at 700 Watts , 59.6 min at 200 Watts

Recharge Time: 3 hours

Features: Maintenance free, sealed, leak-proof

Networking

Remote Management Interface: RS-232, USB

Expansion / Connectivity

Interfaces: 1 x management (RS-232) - RJ-45 , 1 x EPO (emergency power off) , 1 x management (USB)

Expansion Slots: 1 (total) / 1 (free) x SmartSlot

Miscellaneous

Cables Included: Power cable 1.83 m , USB cable - external

Rack Mounting Kit: Included

Features: Audible alarm, LCD display, internal bypass, LED indicators, cold-start function, firmware upgradable, automatic self-test, hot-swappable batteries, Eco-Mode, reset breaker
