APC Smart UPS 750VA 230V USB with UL Approval
Description
APC Smart-UPS protects critical data by supplying reliable, network-grade power in either traditional tower or rack-optimized form factors. Award-winning Smart-UPS is the perfect UPS for protecting business critical servers, voice and data networks, point of sale, retail/bank back office and ATMs. Smart-UPS is a UPS businesses trust for their critical applications.
Highlights of the APC Smart UPS 750VA 230V USB with UL Approval
- Global safety approvals
-
Global safety approvals
UL60950, CSA60950, IEC60950, EN60950 safety approvals. Meets IEC 61000-4-5 Immunity To Surge, and GR-1089-CORE, Section 4, Lightning and AC Power Faults standards.
Specifications
Summary
- Product Description
- APC Smart-UPS 750 - UPS - 500 Watt - 750 VA
- Device Type
- UPS - external
- Weight
- 13.2 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 220/230/240 V ± 5%
- Power Capacity
- 500 Watt / 750 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 6 x power IEC 60320 C13
- Battery
- Lead Acid
- Battery Form Factor
- Internal
- Batteries Qty
- 1
- Run Time (Up To)
- 4.8 min at full load
- Networking
- USB
- Colour
- Black
- Dimensions (WxDxH)
- 13.7 cm x 35.8 cm x 15.7 cm
Detailed Specification
General
- Device Type
- UPS - external
- Battery Enclosure Type
- Internal
- Colour
- Black
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 160 - 286 V
- Input Voltage Range (Adjustable)
- AC 151 - 302 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 6 x power IEC 60320 C13
- Output Voltage
- AC 220/230/240 V ± 5% - 50/60 Hz
- Power Capacity
- 500 Watt / 750 VA
- Output Waveform
- Sinewave
- Surge Suppression
- Yes
- Surge Energy Rating
- 340 Joules
Battery
- Quantity
- 1
- Technology
- Lead Acid
- Run Time (Up To)
- 4.8 min at full load
- Recharge Time
- 3 hours
Networking
- Remote Management Interface
- USB
Expansion / Connectivity
- Interfaces
- 1 x management (USB) - 4 pin USB Type B
- Expansion Slots
- 1 (total) / 1 (free) x SmartSlot
Miscellaneous
- Cables Included
- USB cable
- Features
- Audible alarm, LED indicators
- Compliant Standards
- UL, C-Tick, GOST, UL 1449, VDE, IEC 60950, EN 50091-2, EN 50091-1
Software / System Requirements
- Software Included
- Drivers & Utilities
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95%
- Sound Emission
- 55 dBA
Dimensions & Weight
- Width
- 13.7 cm
- Depth
- 35.8 cm
- Height
- 15.7 cm
- Weight
- 13.2 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 27.3 cm
- Shipping Depth
- 49.5 cm
- Shipping Height
- 27.9 cm
- Shipping Weight
- 14.6 kg
