Name: APC Smart-UPS 3000VA LCD RM - UPS (Rack-Mountable) AC 230 V
Price: 2000.57 GBP
Availability: InStock
Rating: 0.0 (0 reviews)

Description

APC Smart-UPS protects your data by supplying reliable, network-grade power in either traditional Tower or Rack-optimized form factors for space constrained business critical applications. Award winning APC Smart-UPS is the perfect UPS for protecting business critical fileservers (Intel or UNIX based), minicomputers, network switches and hubs, Point of Sale, retail/bank back office and ATMs. Rack Mount versions are the choice for rack optimized servers, server appliances, blade servers, other blade devices and rack-mounted network switches and hubs.

Highlights of the APC Smart-UPS 3000VA LCD RM - UPS (Rack-Mountable) AC 230 V

Predicitive failure notification - provides early-warning fault analysis ensuring proactive component replacement
Wide input voltage range - designed for harsh electrical environments to save battery life
LED indicators - provide easy-to-read status of the unit and utility power conditions
Boost and Trim Automatic Voltage Regulation (AVR) - eliminates voltage fluctuations as a source of AV signal degradation and component power-supply stress
High online efficiency - reduces utility costs, generates less heat
Energy meter - provides actual kilowatt hours of usage for energy conscious users
Predictive replace battery date - dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning
Intuitive LCD interface - provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys
Single switched outlet group - single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding
Sequenced network shutdown and reboot - customize network shutdown and reboot sequence of connected servers and UPSs
Outlet group control - turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations
Adjustable voltage sensitivity - provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications
Adjustable voltage-transfer points - maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation
Audible alarms - provides notification of changing utility power and UPS power conditions
Automatic restart of loads after UPS shutdown - automatically starts up the connected equipment upon the return of utility power
Automatic self-test - periodic battery self-test ensures early detection of a battery that needs to be replaced
Cold-start capable - provides temporary battery power when the utility power is out
Hot-swappable batteries - ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Network manageable - provides remote power management of the UPS over the network
Battery failure notification - provides early-warning fault analysis on batteries enabling timely preventive maintenance
Safety-agency approved - ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment
Serial connectivity - provides management of the UPS via a serial port
Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
User-replaceable batteries - increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Intelligent battery management - maximizes battery performance, life, and reliability through intelligent, precision charging
Frequency and voltage regulation - gives higher application availability by correcting poor frequency and voltage conditions without using the battery
Intelligent battery management - maximizes battery performance, life, and reliability through intelligent, precision charging
Power conditioning - protects connected loads from surges, spikes, lightning, and other power disturbances
Temperature-compensated battery charging - prolongs battery life by regulating the charge voltage according to battery temperature
Automatic restart of loads after UPS shutdown - automatically starts up the connected equipment upon the return of utility power
Automatic self-test - periodic battery self-test ensures early detection of a battery that needs to be replaced
Disconnected battery notification - warns when a battery is not available to provide backup power
Network manageable - provides remote power management of the UPS over the network
Audible alarms - actively let you know if the unit is on battery, if the battery is low or if there is an overload condition
LED status indicators - quickly understand unit and power status with visual indicators
Serial connectivity - provides management of the UPS via a serial port
Disconnected battery notification - warns when a battery is not available to provide backup power

Specifications

Summary

Product Description: APC Smart-UPS 3000VA LCD RM - UPS - 2700 Watt - 3000 VA - with APC UPS Network Management Card

Device Type: UPS - rack-mountable

Rack Size: 2U

Weight: 44.19 kg

Input Voltage: AC 230 V

Output Voltage: AC 230 V ± 5%

Power Capacity: 2700 Watt / 3000 VA

Input Connectors: 1

Output connectors: 8 x power IEC 60320 C13 , 1 x power IEC 60320 C19

Battery: Lead Acid

Run Time (Up To): 3.2 min at full load

Networking: Ethernet, RS-232, USB

Included Accessories: Rack mounting rails, temperature probe

Colour: Black

Dimensions (WxDxH): 48 cm x 68.3 cm x 8.6 cm

Manufacturer Warranty: 3-year warranty

Bundled with: APC UPS Network Management Card

Designed For: P/N: AR2200, AR2280, AR2487G, AR3100TAA, AR3100W, AR3105SP, AR3105W, AR3107SP, AR3140G, AR3140W, AR3150SP, AR3150W, AR3155SP, AR3155W, AR3157SP, AR3300SP, AR3300W, AR3305SP, AR3305W, AR3307SP, AR3307W, AR3340G, AR3340W, AR3350SP, AR3350W, AR3355SP, AR3355W, AR3357SP, AR4038IX432, NBPD0180, NBWL0356A

Detailed Specification

General

Device Type: UPS - rack-mountable

Height (Rack Units): 2U

Colour: Black

Bundled with: APC UPS Network Management Card

Power Device

UPS Technology: Line interactive

Input Voltage: AC 230 V

Input Voltage Range (Adjustable): AC 151 - 302 V

Frequency Provided: 47 - 63 Hz

Frequency Required: 50/60 Hz ± 3Hz

Input Connectors: 1

Power Output Connectors Details: 8 x power IEC 60320 C13 , 1 x power IEC 60320 C19

Output Voltage: AC 230 V ± 5% - 47 - 63 Hz

Power Capacity: 2700 Watt / 3000 VA

Output Waveform: Sinewave

Surge Suppression: Yes

Surge Energy Rating: 320 Joules

Circuit Protection: Circuit breaker

Battery

Technology: Lead Acid

Run Time (Up To): 3.2 min at full load , 11.5 min at half load

Recharge Time: 3 hours

Transfer Time: 4 ms

Features: Maintenance free, sealed, leak-proof

Networking

Remote Management Interface: Ethernet, RS-232, USB

Expansion / Connectivity

Interfaces: 1 x management (RS-232) - RJ-45 , 1 x management (USB) - 4 pin USB Type B , Management (Ethernet) - RJ-45

Expansion Slots: 1 (total) / 0 (free) x SmartSlot

Miscellaneous

Included Accessories: Rack mounting rails, temperature probe

Cables Included: Serial cable - external , USB cable - external , Power cable - external

Rack Mounting Kit: Included

Features: Audible alarm, LCD display, Automatic Voltage Regulation (AVR), LED indicators, cold-start function, automatic self-test, predicitive failure notification, hot-swappable batteries, energy metre

Compliant Standards: GS, VDE, IEC 62040-2, IRAM, RoHS, WEEE, REACH, EN 62040-2, EAC, RCM, IEC 62040-1, EN 62040-1

Software / System Requirements

Software Included: APC PowerChute Business Edition

Manufacturer Warranty

Service & Support: Limited warranty - 3 years , Limited warranty - batteries - 2 years

Environmental Parameters

Min Operating Temperature: 0 °C

Max Operating Temperature: 40 °C

Humidity Range Operating: 0 - 95%

Sound Emission: 55 dBA

Dimensions & Weight

Width: 48 cm

Depth: 68.3 cm

Height: 8.6 cm

Weight: 44.19 kg

Dimensions & Weight (Shipping)

Shipping Width: 60 cm

Shipping Depth: 98 cm

Shipping Height: 25.4 cm

Shipping Weight: 51.59 kg

Compatibility Information

Designed For: P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF202BLK, ACF400, ACF402, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR201, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3105, AR3105SP, AR3105W, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3180G, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3810, AR3812, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, NBPD0180, NBRK0201, NBRK0320, NBRK0320E, NBRK0551, NBWL0355, NBWL0356A
