APC Back-UPS 1600VA, 230V, AVR, IEC Sockets
Description
APC Back-UPS BX series is a cost-effective power protection solution for home and home office environments. The comprehensive VA range with premium features further enables single UPS capabilities.
Highlights of the APC Back-UPS 1600VA, 230V, AVR, IEC Sockets
- Power surge protection
- Refined power supply
- Instant power
- Compact form factor
- Functional ease of use
- Network protection
- Automatic Voltage Regulation (AVR)
-
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. -
LED Indicators
Provide easy-to-read status of the unit and utility power conditions. -
PowerChute Personal Edition OS Compatibility
This software supports numerous operating systems and processors. /a -
USB connection
Use your PC to access additional power protection and management features for your UPS via a USB Port.
Specifications
Summary
- Product Description
- APC Back-UPS BX Series BX1600MI - UPS - 900 Watt - 1600 VA
- Device Type
- UPS - external
- Weight
- 10.3 kg
- Input Voltage
- AC 230 V
- Output Voltage
- AC 230 V ± 10%
- Power Capacity
- 900 Watt / 1600 VA
- Input Connectors
- 1 x power IEC 60320 C14
- Output connectors
- 6 x power IEC 60320 C13
- Battery
- Lead Acid - 7 Ah
- Batteries Qty
- 2
- Run Time (Up To)
- 6.5 min at half load
- Dimensions (WxDxH)
- 14 cm x 39 cm x 19 cm
- Manufacturer Warranty
- 2-year warranty
Detailed Specification
General
- Device Type
- UPS - external
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 140 - 300 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 6 x power IEC 60320 C13
- Output Voltage
- AC 230 V ± 10% - 50/60 Hz
- Power Capacity
- 900 Watt / 1600 VA
- Dataline Surge Protection
- Network - RJ-45 - 1 input line / 1 output line
- Output Waveform
- Stepped approximation to a sinewave
- Surge Energy Rating
- 273 Joules
- Circuit Protection
- Fuse
Battery
- Quantity
- 2
- Technology
- Lead Acid
- Voltage Provided
- 12 V
- Capacity
- 7 Ah
- Run Time (Up To)
- 6.5 min at 50% load , 1 min at full load
- Recharge Time
- 8 hours
- Transfer Time
- 6 ms
- Features
- Maintenance free, sealed
Expansion / Connectivity
- Interfaces
- 1 x USB
Miscellaneous
- Cables Included
- Power cable - external - 1.2 m
- Features
- Audible alarm, Automatic Voltage Regulation (AVR)
- Compliant Standards
- CB, IEC 62040-2, IP20, IEC 62040-1, EN 62040-1
Software / System Requirements
- Software Included
- APC PowerChute Personal Edition
Manufacturer Warranty
- Service & Support
- Limited warranty - replace or repair - 2 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 - 95%
Dimensions & Weight
- Width
- 14 cm
- Depth
- 39 cm
- Height
- 19 cm
- Weight
- 10.3 kg
Dimensions & Weight (Shipping)
- Shipping Width
- 23.5 cm
- Shipping Depth
- 49.5 cm
- Shipping Height
- 29.7 cm
- Shipping Weight
- 11.3 kg
